Points, Lines, Planes, and Angle Relationships: math test solutions, Grade 10 (Free PDF)

  • by
Test solutions Grade 10 : Points, Lines, Planes, and Angle Relationships — Zyro the alien explorer of Planète Maths

Test solutions angle relationships grade 10 : test solutions with the detailed point scale. Add up your points and spot what to review.

Key takeaway: Worked answers for the Grade 10 test on Points, Lines, Planes, and Angle Relationships, with the scoring for each problem: segment addition, adding angles and vertical angles. Use it to grade yourself after a timed attempt; free PDF.

Suggested time: 45 minutes. Out of 20 points. Calculator allowed only when the problem says so.

1 Vocabulary / 3 pts (test solutions angle relationships grade 10)

(a) Two points. (1 pt) (b) Three. (1 pt) (c) The segment has two endpoints and a finite length; the ray has one endpoint at \(A\) and extends forever through \(B\). (1 pt)

2 Segment addition / 3 pts

\((4x - 3) + (2x + 9) = 48\), so \(6x + 6 = 48\) and \(x = 7\). (1 pt) \(RS = 25\text{ cm}\) (1 pt) and \(ST = 23\text{ cm}\) (1 pt). Check: \(25 + 23 = 48\).

3 Coordinates / 4 pts (test solutions angle relationships grade 10)

(a) \(\left(\dfrac{-2 + 10}{2}, \dfrac{-1 + 8}{2}\right) = (4, 3.5)\). (2 pts) (b) \(PQ = \sqrt{12^2 + 9^2} = \sqrt{225} = 15\) units. (2 pts)

4 Adding angles / 4 pts

(a) \(6x + 12 = 132\), so \(x = 20\). (2 pts) (b) \(44^\circ\), \(54^\circ\), \(34^\circ\); the sum is \(132^\circ\). (1 pt) (c) A bisector would make \(66^\circ\) with \(OA\). \(m\angle AOB = 44^\circ\) and \(m\angle AOC = 98^\circ\), so neither does. (1 pt)

5 Vertical angles / 3 pts

Vertical angles are equal: \(7x - 4 = 4x + 23\), so \(x = 9\). (1 pt) \(m\angle 1 = 7(9) - 4 = 59^\circ\). (1 pt) \(\angle 2\) forms a linear pair with \(\angle 1\): \(m\angle 2 = 180 - 59 = 121^\circ\). (1 pt)

6 Construction / 3 pts

Open the compass to more than half of \(AB\) (1 pt). With the same opening, draw arcs centered at \(A\) and at \(B\) that meet above and below the segment, then draw the line through those two points (1 pt). It meets \(\overline{AB}\) at its midpoint and is perpendicular to it. (1 pt)

How to study with test solutions angle relationships grade 10

To make the most of these solutions, start by finding the questions where you lost points. Then reread the expected method. Finally, redo those questions a few days later.

Moreover, steady work on test solutions angle relationships grade 10 is worth more than a last-minute cram session. For example, redo a problem you missed a few days later and check that you can solve it alone.

Zyro also advises you to connect test solutions angle relationships grade 10 with the other chapters of the program for Grade 10. Next, spot the topics you already master and those that still need work. This way, you plan your review with a method.

For points, lines, planes, and angle relationships: math test solutions, grade 10, plan a short, regular session rather than one big block. Then always finish with a quick summary: what you understood, what is still unclear. Finally, write down one question to ask your teacher.
