Key takeaway: This Grade 10 test on Parallel and Perpendicular Lines works as a class assessment or a timed review at home: angles and algebra / 4 pts, prove parallel and slopes of three lines / 4 pts. The detailed answer key with scoring is on a separate page; free PDF.
1 Angles and algebra / 4 pts (test parallel lines grade 10)
Parallel lines \(a\) and \(b\) are cut by a transversal. Two alternate interior angles measure \((7x - 4)^\circ\) and \((5x + 16)^\circ\).
- Write and solve an equation for \(x\). (2 points)
- Find the measure of the angles. (1 point)
- Find the measure of a same-side interior angle of one of them. (1 point)
2 Prove parallel / 3 pts
A transversal crosses lines \(p\) and \(q\). Two same-side interior angles measure \(118^\circ\) and \(62^\circ\). (a) Are \(p\) and \(q\) parallel? Justify. (b) If the angles measured \(118^\circ\) and \(64^\circ\) instead, what would you conclude?
3 Slopes of three lines / 4 pts (test parallel lines grade 10)
Line \(\ell_1\) passes through \((-3, 4)\) and \((1, -2)\). Next, line \(\ell_2\) passes through \((0, 1)\) and \((3, 3)\). Line \(\ell_3\) passes through \((-1, 5)\) and \((3, -1)\). Find the three slopes (3 points) and name the relation between \(\ell_1\) and \(\ell_2\), and between \(\ell_1\) and \(\ell_3\) (1 point).
4 Writing equations / 4 pts
Line \(m\) is \(y = -\dfrac{3}{4}x + 2\). Write an equation of (a) the line through \((8, -1)\) parallel to \(m\) (2 points), and (b) the line through \((8, -1)\) perpendicular to \(m\) (2 points).
5 Distance to a line / 3 pts
Find the distance from the point \(P(1, 2)\) to the line \(3x + 4y + 5 = 0\). Show your work.
6 Perpendicular bisector / 2 pts
Find the equation of the perpendicular bisector of the segment joining \(A(-1, 0)\) and \(B(5, 4)\).
Test parallel lines grade 10: a method to succeed
First, take the test in limited time, without your lesson. Then mark yourself with the scoring guide on the solutions page. This way, you know which topics to work on before the real exam.
In addition, test parallel lines grade 10 sticks better when you practice a little every week, with real calculations. For example, redo a problem you missed a few days later and check that you can solve it alone.
Test yourself: quick challenge for Grade 10
