Some matrices have special directions that they only stretch, never turn. Finding those directions explains how a whole system evolves over time, and combining them with the idea of perpendicular vectors gives you some of the most useful tools in applied mathematics: projections, orthogonal bases and best-fit lines. In this chapter you will learn to compute eigenvalues, diagonalize a matrix, use the dot product to test for orthogonality, project vectors, build orthogonal bases with the Gram-Schmidt process, and fit data with least squares.
1. Eigenvalues and eigenvectors
When a square matrix \(A\) multiplies a vector \(\mathbf{x}\), the result is usually a vector pointing in a new direction. For a few special vectors, the output points along the same line as the input.
Let \(A\) be an \(n\times n\) matrix. A nonzero vector \(\mathbf{v}\) is an eigenvector of \(A\) if
\[A\mathbf{v}=\lambda\mathbf{v}\]
for some number \(\lambda\). The number \(\lambda\) is the corresponding eigenvalue.
The vector \(\mathbf{v}\) must be nonzero (the zero vector would satisfy the equation for every \(\lambda\)), but the eigenvalue \(\lambda\) is allowed to be \(0\) or negative. If \(\lambda<0\), the matrix flips the vector to the opposite direction while stretching or shrinking it.
Let \(A=\begin{pmatrix}2&1\\1&2\end{pmatrix}\), \(\mathbf{v}=\begin{pmatrix}1\\1\end{pmatrix}\) and \(\mathbf{u}=\begin{pmatrix}1\\0\end{pmatrix}\).
\(A\mathbf{v}=\begin{pmatrix}3\\3\end{pmatrix}=3\mathbf{v}\), so \(\mathbf{v}\) is an eigenvector with eigenvalue \(3\).
\(A\mathbf{u}=\begin{pmatrix}2\\1\end{pmatrix}\), which is not a multiple of \(\mathbf{u}\), so \(\mathbf{u}\) is not an eigenvector.
On my home planet we say an eigenvector is a “loyal direction”: the matrix may stretch it, shrink it or flip it, but it never bends it. Look at the figure: v and Av sit on the same line, while u and Au do not.
2. The characteristic polynomial
To find eigenvalues we rewrite \(A\mathbf{v}=\lambda\mathbf{v}\) as \((A-\lambda I)\mathbf{v}=\mathbf{0}\). A nonzero solution \(\mathbf{v}\) exists only when \(A-\lambda I\) is not invertible, that is, when its determinant is zero.
The number \(\lambda\) is an eigenvalue of \(A\) exactly when
\[\det(A-\lambda I)=0.\]
The left side is a polynomial of degree \(n\) in \(\lambda\), called the characteristic polynomial. For a \(2\times 2\) matrix it equals \(\lambda^2-(\text{trace})\lambda+\det A\).
Two checks save a lot of mistakes. The eigenvalues add up to the trace of \(A\) (the sum of the diagonal entries), and they multiply to give \(\det A\). For a triangular matrix, the eigenvalues are simply the diagonal entries.
- Write \(\det(A-\lambda I)=0\) and expand it.
- Solve the polynomial equation to get the eigenvalues.
- For each eigenvalue \(\lambda\), solve \((A-\lambda I)\mathbf{v}=\mathbf{0}\) to find its eigenvectors.
- Check by computing \(A\mathbf{v}\) and comparing with \(\lambda\mathbf{v}\).
Let \(A=\begin{pmatrix}4&-2\\1&1\end{pmatrix}\). Its trace is \(5\) and its determinant is \(4+2=6\), so
\[\det(A-\lambda I)=\lambda^2-5\lambda+6=(\lambda-2)(\lambda-3).\]
The eigenvalues are \(2\) and \(3\).
For \(\lambda=2\): \(A-2I=\begin{pmatrix}2&-2\\1&-1\end{pmatrix}\) gives \(x=y\), so \(\mathbf{v}_1=\begin{pmatrix}1\\1\end{pmatrix}\).
For \(\lambda=3\): \(A-3I=\begin{pmatrix}1&-2\\1&-2\end{pmatrix}\) gives \(x=2y\), so \(\mathbf{v}_2=\begin{pmatrix}2\\1\end{pmatrix}\).
Check: \(A\mathbf{v}_2=\begin{pmatrix}8-2\\2+1\end{pmatrix}=\begin{pmatrix}6\\3\end{pmatrix}=3\mathbf{v}_2\).
A matrix can have no real eigenvalues. The rotation matrix \(\begin{pmatrix}0&-1\\1&0\end{pmatrix}\) has characteristic polynomial \(\lambda^2+1\), which has no real root: no real direction survives a quarter turn.
3. Diagonalization
If an \(n\times n\) matrix has \(n\) linearly independent eigenvectors, we put them as the columns of a matrix \(P\) and the eigenvalues on the diagonal of a matrix \(D\). Then \(AP=PD\).
If \(P\) has eigenvectors of \(A\) as columns and \(D\) is the diagonal matrix of the matching eigenvalues, then
\[A=PDP^{-1}\qquad\text{and}\qquad A^k=PD^kP^{-1}.\]
A matrix with \(n\) distinct eigenvalues is always diagonalizable.
The power formula is the real payoff: raising a diagonal matrix to a power only means raising each diagonal entry to that power.
With \(P=\begin{pmatrix}1&2\\1&1\end{pmatrix}\) and \(D=\begin{pmatrix}2&0\\0&3\end{pmatrix}\), we get \(\det P=-1\) and \(P^{-1}=\begin{pmatrix}-1&2\\1&-1\end{pmatrix}\). Multiplying out confirms
\[PDP^{-1}=\begin{pmatrix}4&-2\\1&1\end{pmatrix}=A.\]
Therefore \(A^{10}\) has eigenvalues \(2^{10}=1024\) and \(3^{10}=59{,}049\), with the same eigenvectors as \(A\).
Not every matrix is diagonalizable. For \(\begin{pmatrix}3&1\\0&3\end{pmatrix}\) the only eigenvalue is \(3\), but every eigenvector is a multiple of \(\begin{pmatrix}1\\0\end{pmatrix}\): there are not enough independent eigenvectors.
4. Dot product and orthogonality
For vectors \(\mathbf{u}=(u_1,\dots,u_n)\) and \(\mathbf{w}=(w_1,\dots,w_n)\),
\[\mathbf{u}\cdot\mathbf{w}=u_1w_1+u_2w_2+\cdots+u_nw_n,\qquad \|\mathbf{u}\|=\sqrt{\mathbf{u}\cdot\mathbf{u}}.\]
Two vectors are orthogonal when \(\mathbf{u}\cdot\mathbf{w}=0\).
The dot product also gives the angle \(\theta\) between two nonzero vectors: \(\cos\theta=\dfrac{\mathbf{u}\cdot\mathbf{w}}{\|\mathbf{u}\|\,\|\mathbf{w}\|}\). Orthogonal means \(\theta=90^\circ\). A set of vectors is orthogonal if every pair is orthogonal, and orthonormal if, in addition, every vector has length \(1\). To normalize a nonzero vector, divide it by its length.
Orthogonality is tied to eigenvalues by one important fact: if a matrix is symmetric (equal to its transpose), eigenvectors that belong to different eigenvalues are always orthogonal. That is why symmetric matrices can be diagonalized with a perfectly “square” set of axes.
For \(\mathbf{u}=(2,-1,2)\) and \(\mathbf{w}=(1,4,3)\): \(\mathbf{u}\cdot\mathbf{w}=2-4+6=4\), so they are not orthogonal. Also \(\|\mathbf{u}\|=\sqrt{4+1+4}=3\), so \(\mathbf{u}/3=\left(\tfrac23,-\tfrac13,\tfrac23\right)\) is a unit vector.
5. Orthogonal projections
To project a vector \(\mathbf{b}\) onto the line through the origin spanned by a nonzero vector \(\mathbf{a}\), we look for the point on that line closest to \(\mathbf{b}\). It is the point where the leftover “error” is perpendicular to \(\mathbf{a}\).
\[\operatorname{proj}_{\mathbf{a}}\mathbf{b}=\frac{\mathbf{b}\cdot\mathbf{a}}{\mathbf{a}\cdot\mathbf{a}}\,\mathbf{a}.\]
The error \(\mathbf{b}-\operatorname{proj}_{\mathbf{a}}\mathbf{b}\) is orthogonal to \(\mathbf{a}\), and its length is the distance from \(\mathbf{b}\) to the line.
Let \(\mathbf{a}=(3,1)\) and \(\mathbf{b}=(1,5)\). Then \(\mathbf{b}\cdot\mathbf{a}=8\) and \(\mathbf{a}\cdot\mathbf{a}=10\), so
\[\operatorname{proj}_{\mathbf{a}}\mathbf{b}=\tfrac{8}{10}(3,1)=(2.4,\,0.8).\]
The error is \((1,5)-(2.4,0.8)=(-1.4,\,4.2)\), and \((-1.4)(3)+(4.2)(1)=0\), as expected. The distance from \(\mathbf{b}\) to the line is \(\sqrt{1.96+17.64}=\sqrt{19.6}\approx 4.43\).
6. The Gram-Schmidt process
Orthogonal bases make computations easy, but a basis you are handed is rarely orthogonal. Gram-Schmidt repairs it one vector at a time: keep the first vector, then subtract from each new vector its projections onto the vectors already built.
Start from independent vectors \(\mathbf{v}_1,\mathbf{v}_2,\mathbf{v}_3,\dots\)
- \(\mathbf{u}_1=\mathbf{v}_1\).
- \(\mathbf{u}_2=\mathbf{v}_2-\operatorname{proj}_{\mathbf{u}_1}\mathbf{v}_2\).
- \(\mathbf{u}_3=\mathbf{v}_3-\operatorname{proj}_{\mathbf{u}_1}\mathbf{v}_3-\operatorname{proj}_{\mathbf{u}_2}\mathbf{v}_3\), and so on.
- To get an orthonormal basis, divide each \(\mathbf{u}_i\) by its length.
Take \(\mathbf{v}_1=(3,1)\) and \(\mathbf{v}_2=(2,2)\). Then \(\mathbf{u}_1=(3,1)\) and \(\mathbf{v}_2\cdot\mathbf{u}_1=8\), \(\mathbf{u}_1\cdot\mathbf{u}_1=10\), so
\[\mathbf{u}_2=(2,2)-\tfrac{8}{10}(3,1)=(2,2)-(2.4,0.8)=(-0.4,\,1.2).\]
Check: \(\mathbf{u}_1\cdot\mathbf{u}_2=-1.2+1.2=0\).
7. Least squares
Real data rarely fit a line exactly. A system \(A\mathbf{x}=\mathbf{b}\) with more equations than unknowns usually has no solution, so we look for the vector \(\hat{\mathbf{x}}\) that makes \(A\hat{\mathbf{x}}\) as close as possible to \(\mathbf{b}\). Closest means the error \(\mathbf{b}-A\hat{\mathbf{x}}\) is orthogonal to every column of \(A\), which is a projection of \(\mathbf{b}\) onto the column space of \(A\).
The least squares solution of \(A\mathbf{x}=\mathbf{b}\) satisfies
\[A^{T}A\,\hat{\mathbf{x}}=A^{T}\mathbf{b}.\]
It minimizes the sum of the squared errors \(\|\mathbf{b}-A\hat{\mathbf{x}}\|^2\).
Fit \(y=a+bx\) to the points \((1,2),(2,3),(3,5),(4,6)\). The columns of \(A\) are \((1,1,1,1)\) and \((1,2,3,4)\), and \(\mathbf{b}=(2,3,5,6)\). Then
\[A^TA=\begin{pmatrix}4&10\\10&30\end{pmatrix},\qquad A^T\mathbf{b}=\begin{pmatrix}16\\47\end{pmatrix}.\]
Solving gives \(a=0.5\) and \(b=1.4\), so the line is \(y=0.5+1.4x\). The residuals are \(0.1,\,-0.3,\,0.3,\,-0.1\), and the sum of squared errors is \(0.2\).
The same idea works for curves: a parabola \(y=a+bx+cx^2\) only needs a third column \((x_1^2,\dots,x_n^2)\) in \(A\). The method stays the same.
Key takeaways
- An eigenvector satisfies \(A\mathbf{v}=\lambda\mathbf{v}\) with \(\mathbf{v}\neq\mathbf{0}\); \(\lambda\) is its eigenvalue.
- Eigenvalues are the roots of \(\det(A-\lambda I)=0\); their sum is the trace and their product is the determinant.
- \(A=PDP^{-1}\) when there are enough independent eigenvectors, and then \(A^k=PD^kP^{-1}\).
- \(\mathbf{u}\cdot\mathbf{w}=0\) means orthogonal; eigenvectors of a symmetric matrix for different eigenvalues are orthogonal.
- \(\operatorname{proj}_{\mathbf{a}}\mathbf{b}=\dfrac{\mathbf{b}\cdot\mathbf{a}}{\mathbf{a}\cdot\mathbf{a}}\,\mathbf{a}\), and the error is perpendicular to \(\mathbf{a}\).
- Gram-Schmidt subtracts projections to turn independent vectors into an orthogonal set.
- Least squares solves \(A^TA\hat{\mathbf{x}}=A^T\mathbf{b}\) to find the best fit.
