Key takeaway: This Grade 10 test on Circles works as a class assessment or a timed review at home: tangents, inscribed angles and arc and sector. The detailed answer key with scoring is on a separate page; free PDF.
1 Tangents / 3 pts
A circle has center \(O\) and radius \(9\) cm. The point \(P\) is \(15\) cm from \(O\). Two tangent segments \(PT\) and \(PS\) are drawn to the circle. (a) Find \(PT\). (b) What is \(PS\)? Explain.
2 Inscribed angles / 4 pts
Points \(A, B, C, D\) lie on a circle and split it into arcs \(\widehat{AB} = 84^\circ\), \(\widehat{BC} = 96^\circ\), \(\widehat{CD} = 70^\circ\), \(\widehat{DA} = 110^\circ\) (see the figure).
(a) Find \(m\angle ACB\). (b) Find \(m\angle ABD\). (c) Find \(m\angle ABC\) and explain what it tells you about \(AC\). (d) Find \(m\angle DAB\) and \(m\angle BCD\), and show that they are supplementary.
3 Arc and sector / 4 pts
A circle has radius \(15\) cm. A sector has a central angle of \(48^\circ\). Find (a) the length of the arc and (b) the area of the sector. Give exact values, then round to the nearest hundredth. Calculator allowed.
4 Segment lengths / 4 pts
(a) Chords \(AB\) and \(CD\) meet at \(E\) with \(AE = 8\), \(EB = 3\), \(CE = 4\). Find \(ED\). (b) From a point \(P\), a tangent of length \(6\) and a secant with external part \(4\) are drawn. Find the length of the whole secant and of the chord inside the circle.
5 Equation of a circle / 3 pts
Consider \(x^2 + y^2 - 12x + 4y + 15 = 0\). (a) Rewrite it in standard form. (b) Give the center and radius. (c) Does the point \((2, 1)\) lie on the circle?
6 Angle outside a circle / 2 pts
Two secants meet at a point outside a circle. The far arc measures \(130^\circ\) and the near arc measures \(46^\circ\). Find the measure of the angle formed by the secants.
Test yourself: quick challenge for Grade 10
